P3 Indoor 1/16 Scan 192*96mm LED Module
|
| Specification |
Model No.:P3-I16S-SMD2121-64×32 |
| LED Lamp Specification |
| Color |
Package |
Intensity |
Viewing Angle |
Wavelength |
Testing Conditions |
| Red |
SMD2121 |
70-100mcd |
120°/120° |
620-625nm |
25℃,20mA |
| Green |
SMD2121 |
120-200mcd |
120°/120° |
515-530nm |
25℃,10mA |
| Blue |
SMD2121 |
30-40mcd |
120°/120° |
465-475nm |
25℃,5mA |
|
|
|
| Pixel Pitch |
3mm |
| Pixel Configuration |
SMD2121 |
| Density |
111,111 pixels/㎡ |
| Module Resolution |
64pixel(L) * 32pixel(H) |
| Module Dimension18mm(D) |
192mm(L) * 96mm(H) * |
| Driving Mode |
Constant current, 1/16 duty |
| Module Mask |
Pure black mask–high contrast screen |
| Electricity Parameter |
| Optical Ratings |
|
| Brightness |
≥1,600 cd/㎡ |
| Viewing Angle |
120°(Horizontal)； 120°(Vertical) |
| Best Viewing Distance |
≥3m |
| Gray Grade |
14 bits |
| Display Color |
4.4 trillion colors |
| Brightness |
Adjustment 100 grades by software or automatically by sensor |
| Max. Power Consumption |
18 W |
| Control System |
| Frame Frequency |
≥60Hz |
| Refresh Frequency |
≥1,920Hz |
| Input Signal Composite Video |
S-video, DVI, HDMI, SDI, HD-SDI |
| Control Distance |
100m(Ethernet cable ); 20KM(optical fiber cable) |
| Support |
VGA Mode 800*600, 1024*768, 1280*1024, 1600*1200 |
| Color Temperature |
5000—9300 adjustable |
| Brightness Correction |
Pixel by pixel, module by module, cabinet by cabinet |
| Reliability |
| Working Temperature |
(-20～+60 ºC) |
| Storage Temperature |
( -30～+70 ºC) |
| Working Humidity |
10%～90% RH |
| Lifetime |
100,000 hours |
| Mean Time Between Failures ( MTBF) |
5000 hours |
| Continuous Operating Time |
≥72 hours |
| Protection Grade |
IP31 |
| Out-of-Control Pixel Rate |
≤0.01% |
