P4 Outdoor LED Fixed Video Wall RGB with WiFi/LAN

Sale!

P4 Outdoor SMD2525 256*128mm LED Module
Specification			Model No.: P4-O8S-SMD2525-64×32
LED Lamp Specification
Color	Package	Intensity	Viewing Angle	Wavelength	Testing Conditions
Red	SMD2525	450-600mcd	120°/120°	620-625nm	25℃,20mA
Green		1000-1400mcd	120°/120°	516-530nm	25℃,20mA
Blue		200-400mcd	120°/120°	465-475nm	25℃,20mA

Module Parameter
Pixel Pitch			4mm
Pixel Configuration			SMD2525
Density			62,500 pixels/㎡
Module Resolution			64pixel(L) * 32pixel(H)
Module Dimension			256mm(L) * 128mm(H) * 18mm(D)
Driving Mode			Constant current, 1/8 duty
Module Mask			Pure black mask–high contrast screen
Electricity Parameter
Optical Ratings
Brightness			≥6,000 cd/㎡
Viewing Angle			120°(Horizontal)； 120°(Vertical)
Best Viewing Distance			≥4m
Gray Grade			16 bits
Display Color			4.4 trillion colors
Brightness Adjustment			100 grades by software or automatically by sensor
Max. Power Consumption			30 W
Control System
Frame Frequency			≥60Hz
Refresh Frequency			≥1,920Hz
Input Signal			Composite Video, S-video, DVI, HDMI, SDI, HD-SDI
Control Distance			100m(Ethernet cable ); 20KM(optical fiber cable)
Support VGA Mode			800600, 1024768, 12801024, 16001200
Color Temperature			5000—9300 adjustable
Brightness Correction			Pixel by pixel, module by module, cabinet by cabinet
Reliability
Working Temperature			(-20～+60 ºC)
Storage Temperature			( -30～+70 ºC)
Working Humidity			10%～90% RH
Lifetime			100,000 hours
Mean Time Between Failures ( MTBF)			5000 hours
Continuous Operating Time			≥72 hours
Protection Grade			IP65
Out-of-Control Pixel Rate			≤0.01%
