| P6 Outdoor 1/8 Scan 192*192mm LED Module |
| Specification |
Model No.:P6-O8S-SMD3535-32×32 |
| LED Lamp Specification |
| Color |
Package |
Intensity |
Viewing Angle |
Wavelength |
Testing Conditions |
| Red |
SMD3535 |
800-1100mcd |
120°/120° |
620-625nm |
25℃,20mA |
| Green |
1600-2250mcd |
120°/120° |
516-530nm |
25℃,20mA |
| Blue |
350-500mcd |
120°/120° |
465-475nm |
25℃,20mA |
|
| Module Parameter |
| Pixel Pitch |
6mm |
| Pixel Configuration |
SMD3535 |
| Density |
27,778 pixels/㎡ |
| Module Resolution |
32pixel(L) * 32pixel(H) |
| Module Dimension |
192mm(L) * 192mm(H) * 25mm(D) |
| Driving Mode |
Constant current, 1/8 duty |
| Module Mask |
Pure black mask–high contrast screen |
| Electricity Parameter |
| Optical Ratings |
|
| Brightness |
≥6500 cd/㎡ |
| Viewing Angle |
120°(Horizontal)； 120°(Vertical) |
| Best Viewing Distance |
≥6m |
| Gray Grade |
14 bits |
| Display Color |
4.4 trillion colors |
| Brightness Adjustment |
100 grades by software or automatically by sensor |
| Max. Power Consumption |
25 W |
| Control System |
| Frame Frequency |
≥60Hz |
| Refresh Frequency |
≥1,920Hz |
| Input Signal |
Composite Video, S-video, DVI, HDMI, SDI, HD-SDI |
| Control Distance |
100m(Ethernet cable ); 20KM(optical fiber cable) |
| Support VGA Mode |
800*600, 1024*768, 1280*1024, 1600*1200 |
| Color Temperature |
5000—9300 adjustable |
| Brightness Correction |
Pixel by pixel, module by module, cabinet by cabinet |
| Reliability |
| Working Temperature |
(-20～+60 ºC) |
| Storage Temperature |
( -30～+70 ºC) |
| Working Humidity |
10%～90% RH |
| Lifetime |
100,000 hours |
| Mean Time Between Failures ( MTBF) |
5000 hours |
| Continuous Operating Time |
≥72 hours |
| Protection Grade |
IP65 |
| Out-of-Control Pixel Rate |
≤0.01% |
|
